泛光灯

隧道-200w

■ General Description描述

适合于室外照明，如一些公共场所，隧道等等用，主要包括隧道灯的电气特性、光学特性、结构特性、产品认证、环保及可靠性要求。

Suitable for outdoor lighting, such as some public places, tunnels and so on, including the electrical characteristics of tunnellights,opticalcharacteristics,structuralcharacteristics,productcertification,environmentalprotectionand reliability requirements.

■ Applications产品应用

● Tunnels, factories, warehouses, toll booth.
隧道、厂房、仓库、公路收费站.

● Gas stations, supermarket, exhibition hall, sports venues.
加油站、大型超市、展览馆、体育场馆.

● Hall, conference room, shopping malls.
大厅、会议室、商场.+

■ Technical Parameters技术参数

● Lighting parameters灯具参数

Item	HXD-TTL-S2-200W
Power	200W
Input voltage	AC90-265V
Driver	隔离isolated内置 built-in
Frequency	50-60HZ
PF	>0.9
LED Quantity	飞利浦3030 6V/1W 256pcs
Light efficiency	≧150LM/W
Lumen	30000LM -32000LM
Color Temperature	2800k-6500k
CRI	Ra＞80
Beam angle	150°，103°
Lifespan	≧25000Hrs
IP	IP66
